| Make and model | : | UD Trucks, TD42T Diesel Engine |
| Type | : | 4 cycle, indirect injection, water cooled, turbochanged |
| Number of cylinders | : | 6 |
| Bore x stroke | : | 96 mm x 96 mm |
| Total piston displacement | : | 4,169 cc |
| Max. output (JIS) | : | 130PS @ 3,500 rpm |
| Max. Torque (JIS) | : | 29 kg.m @ 2,000 rpm |
| Max.Engine Speed (RPM) | : | 3,700 |
| Compression Ratio | : | 18.5 : 1 |
| Lubrication system | : | Forced feed by gear pump |
| Cooling system | : | Forced feed by centrifugal water pump |
Fuel System |
||
| Fuel Injection Pump | : | In-line Zexel |
| Covernor | : | Zexel |
| Air cleaner | : | Dry paper element type with cyclone |
Weight (kg) |
||
| Gross Vehicle Weight | : | 8,300 |
Dimensions (mm) |
||
| Wheelbase (WB) | : | 3,795 |
| Overall Length (OL) | : | 6,860 |
| Overall Width (OW) | : | 2,125 |
| Overall Height (OH) | : | 780 |
| Front Tread (FT) | : | 1,665 |
| Rear Tread (RT) | : | 1,540 |
| Front Overhang (FOH) | : | 1,330 |
| Rear Overhang (ROH) | : | 1,730 |
